HFC620
Auxiliary contacts, HDC3, FC6-20, side, 2 NO
Main
Range of product
HDC3
Product or component type
Auxiliary contact block
Mounting location
Front
Auxiliary contact composition
3 NO + 1 NC
Complementary
Product compatibility
HDC3 contactor 6…95 A
HDC3 contactor 120…630 A
HDC3 contactor 120…630 A
Auxiliary contacts operation
Instantaneous
Shielding continuity terminal
Without
[Ui] rated insulation voltage
380 V conforming to IEC 60947-5-1
[Ith] conventional free air thermal current
10 A
Environment
Environmental characteristic
Harsh environment
Standards
IEC 60947-5-1
Product certifications
SEMKO
IP degree of protection
IP20
Ambient air temperature for operation
-25…70 °C
Ambient air temperature for storage
-25…70 °C
Operating altitude
2000 m
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Offer Sustainability
Sustainable packaging
No
