Roll over image to zoom in
Click to expand
The product images shown are for illustration purpose only and may not be an exact representation of the product
HLMK61500120
Current transformer, HLMK, 0.66 kV, 1500/5 A, class 0.5
Main
Range of product
HLMK
Product or component type
Current transformer
Maximum rated voltage
0.66 kV
Accuracy class
Class 0.5
Primary current
1500 A
Device application
Metering
Complementary
Rated power in VA
15 VA
Secondary current
5 A
Network type
AC
Network frequency
50/60 Hz
Number of inputs
1
Input type
Current input CT...X/5 A
Type of measurement
Current
Diameter
60 mm
Busbar cross section
120 x 25 mm
80 x 30 mm
80 x 30 mm
Actual number of turns
1
Height
136 mm
Width
190 mm
Depth
41 mm
Environment
IP degree of protection
IP65
Standards
IEC 60044-1
Operating altitude
2000 m
Ambient air temperature for operation
-5…40 °C
Relative humidity
0…90 %
Offer Sustainability
Sustainable packaging
No
