HDY3654440
Surge Protective Device HDY3 -65 - 4P - 440V
Main
Range of product
HDY3
Product or component type
Surge protection device
Body type
Plug-in
Complementary
Poles description
4P
Nominal discharge current
30.0 kA
Maximum discharge current
65.0 kA
[Uc] maximum continuous operating voltage
440.0 V
Maximum [Up] voltage protection level
3.5 kV
Remote signalling
Without
[Ue] rated operational voltage
125 V
Local signalling
Indicator light (green) for operating
Indicator light (red) for fault
Indicator light (red) for fault
Mounting support
35 mm DIN rail
Location of connection
Top
Cable cross section
4…16 mm² flexible cable
4…25 mm² rigid cable
4…25 mm² rigid cable
Response time
<= 25 ns
Height
100 mm
Width
72 mm
Depth
70 mm
Environment
Electromagnetic compatibility
8/20 µs wave immunity
Operating altitude
<= 2000 m
Standards
IEC 61643-1
| Language | Format | Size | Date | |
|---|---|---|---|---|
| User guide | ||||
English |
2.48 MB |
08/06/2020 |
||
User guide
HDY3 UM
pdf
English
2.48 MB
08/06/2020
